About cholestasis and jaundice

WHAT IS CHOLESTASIS?

Cholestasis is defined as reduced bile formation or flow resulting in the retention of biliary substences within the liver normally excreted into bile and destined for elimination into intestinal lumen.3 It may be caused by intrahepatic or extrahepatic disorders.4

The presence of any of the following signs is highly suggestive of cholestasis:3-5

WHAT IS JAUNDICE?

Jaundice refers to the yellowish discolouration of the skin, sclera, and mucous membranes caused by hyperbilirubinaemia resulting from a metabolic imbalance favouring bilirubin production over hepatic-enteric bilirubin clearance.6

Jaundice can be caused by:5

Jaundice can be caused by unconjugated (indirect) hyperbilirubinaemia or conjugated (direct) hyperbilirubinaemia.5 Normally, bilirubin circulates in the plasma, mainly in unconjugated (indirect) form bound to albumin, with only a fraction (<5%) circulating in conjugated form. 5

Unconjugated hyperbilirubinaemia is never a sign of cholestasis while, conversely, conjugated hyperbilirubinaemia is theoretically synonymous with the condition. Certain rare medical conditions may be associated with conjugated hyperbilirubinaemia such as Rotor syndrome and Dubin-Johnson syndrome, but they are so rare that in practice, conjugated hyperbilirubinaemia should evoke cholestasis.5

Cholestatic jaundice VS physiological jaundice

Cholestatic jaundice
VS
physiological jaundice

Distinguishing jaundice caused by cholestasis from noncholestatic conditions (such as physiologic jaundice of the newborn) is critical because cholestatic jaundice is likely to be pathologic and therefore patients with cholestatic jaundice will benefit from prompt diagnosis and institution of specific therapy.3

Early recognition of neonatal cholestasis is essential to ensure timely treatment and optimal prognosis.4

Physiological jaundice results from physiological haemolysis and immaturity of the glucuronoconjugation process. An example of this is “mother’s milk jaundice”, which is observed in 2 to 3% of breastfed newborns or young infants. The precise cause is not known, but the condition is generally mild and transient and stool colouration is in the normal range.5

Cholestasis occurs most often in the neonatal period and affects around 1 in 2,500 term neonates.3

Cholestatic jaundice is always pathologic and suggests hepatobiliary dysfunction.3

The most common cause of cholestatic jaundice in the first months of life is biliary atresia, accounting for 25 to 40% of the cases of cholestatic jaundice at this age.3 It is essential that biliary atresia be diagnosed as early as possible because the prognosis depends very much on how soon surgery is performed.5

Physiological jaundice in newborns

Physiological jaundice is a ubiquitous and often benign condition in newborns manifesting in the first days of life.6

Approximately 60% of term and 80% of preterm babies develop jaundice in the first week of life and about 10% of breastfed babies are still jaundiced at 1 month.7 For most babies, jaundice is not an indication of an underlying disease, and this early jaundice (termed “physiological jaundice”) is usually harmless.

Breastfed babies are more likely than bottle-fed babies to develop physiological jaundice within the first week of life.7

Prolonged jaundice – that is, jaundice persisting beyond the first 14 days – is also seen more commonly in breastfed babies. Prolonged jaundice is usually harmless, but can sometimes be an indication of serious liver disease.7

Infants who are still jaundiced after 2 weeks of age should be evaluated for cholestasis with measurement of total and direct sreum bilirubin, and that an elevated serum direct bilirubin level warrants timely consideration for evaluation and referral to a pediatric gastroenterologist or hepatologist.3

3. Fawaz R, Baumann U, Ekong U, et al. Guideline for the evaluation of cholestatic jaundice in infants: joint recommendations of the North American Society for Pediatric Gastroenterology, Hepatology, and Nutrition and the European Society for Pediatric Gastroenterology, Hepatology, and Nutrition. J PediatrGastroenterol Nutr 2017;64(1):154-68.

4. Feldman AG, Sokol RJ. Neonatal cholestasis. Neoreviews 2013;14(2):10.1542/neo.14-2-e63.

5. Protocole national de diagnostic et de soins : Déficits de synthèse des acides biliaires primaires. In: Génétiques CdRCdlAdVBedC, ed., 2019.

6. Olusanya BO, Kaplan M, Hansen TWR. Neonatal hyperbilirubinaemia: a global perspective. The Lancet 2018;2(8):610-20.

7. Jaundice in newborn babies under 28 days. Updated October 2016 ed. London: NICE: National Institute for Health and Care Excellence, 2010.

​TH-BAS07EN/01/02/2024

Causes of jaundice in newborn or infant5

Jaundice of the newborns or infants

Unconjugated hyperbilirubinaemia

Mechanical haemolysis

Other causes of haemolysis

Intramedullary haemolysis

Infection-related haemolysis

Immune haemolysis

Constitutional haemolysis

Haemolysis

Default in the conjugation of
indirect bilirubin (UGT1A gene)

Rare genetic deficiency of canalicular
or sinusoidal specific transporter of
conjugated bilirubin

Moderate or severe hereditary
deficiency of enzyme activity

Enzyme immaturity or
enzymatic inhibition

Hepatocellular insufficiency

Cholestasis (decreased bile flow)

Other (hypothyroidism, trisomy 21)

Conjugated hyperbilirubinaemia

​TH-BAS07EN/01/02/2024

Bilirubin metabolism5-7

Unconjugated
bilirubin

Bilirubin is mainly
produced from the
break down of red
blood cells.

Red cell breakdown
produces unconjugated
(“indirect”) bilirubin,
which circulates mostly
bound to albumin,
although some is
“free” and hence
able to enter the brain.

The terms “direct”
and “indirect” refer
to the way laboratories
measure the different
forms.

Unconjugated bilirubin
is metabolised in the
liver to produce
conjugated (“direct”)
bilirubin by uridine
diphosphate
glucuronosyltransferase.

The activity of this
enzyme only rises after
birth to reach adult like
values around the age
of three months.

Conjugation of bilirubin
increases its solubility
and facilitates its
secretion into bile.

Conjugated (“direct”)
bilirubin then passes
into the gut and is
largely excreted.

In the gastrointestinal
tract, bilirubin is modified
by digestive bacteria and
transformed into
urobilinogens . A large
portion remains in the
intestine and is
converted into stercobilin
(responsible for the
brown colour of faeces).
Some is reabsorbed into
the bloodstream and the
remainder is excreted in
the urine (urobilin is
responsible for the
yellow colour of urine).

Reticuloendothelial
system

Red blood cells

albumin

Haeme

Blood

“Indirect bilirubin”

“Direct bilirubin”

Liver

Intestine

Conjugated
bilirubin

Urobilinogens

Uridine
diphosphate
glucuronosyl-
transferase

Excreted in bile

Gut bacteria

Enterohepatic
circulation

Excreted in urine
(urobilin)

Excreted in faeces
(stercobilin)

Unconjugated
bilirubin-albumin
complex

​TH-BAS07EN/01/02/2024

Normal values:

Vitamin A: 30–120 μg/dL

Vitamin D: 20–100 ng/mL

Vitamin E: 5–20 μg/mL

Normal values:

Total bilirubin: 0-1.1 mg/dL

Vitamin A: 20-43 µg/dL

Vitamin E: 2.9 – 16.6 mg/L

Vitamin K1: 80-160 pg/mL

Normal values:

Serum calcium: 8.7 – 9.8 mg/dL

Serum phosphorous: 3.9 – 6.5 mg/dL

PTH: 15 – 65 pg/mL

If you click on “access to the link”, you will move on to another website in a new tab

CTRS is not responsible for the content on this website

If you click on “access to the link”, you will move on to another website in a new tab

CTRS is not responsible for the content on this website

If you click on “access to the link”, you will move on to another website in a new tab

CTRS is not responsible for the content on this website

If you click on “access to the link”, you will move on to another website in a new tab

CTRS is not responsible for the content on this website

If you click on “access to the link”, you will move on to another website in a new tab

CTRS is not responsible for the content on this website

Enzymatic pathways of bile acid synthesis

classic pathway

adapted from Sundaram 20081 and Monte 20092

Cholesterol

Cholesterol 7α-hydroxylase
CYP7A1

3β-hydroxy-Δ5 -C27-steroid dehydrogenase
HSD3B7

Δ4-3-oxosteroid-5β-reductase
AKR1D1

Δ4-3-oxosteroid-5β-reductase
AKR1D1

3α-hydroxysteroid dehydrogenase
AKR1C4

Sterol 27-hydroxylase
CYP27A1

Bile acid CoA synthetase (BACS)
or very long chain acyl CoA
synthetase (VLCS)

Side-chain modification by
4 peroxisomal enzymes
(AMACR, BCOX, BDP, SCPx)

3α-hydroxysteroid dehydrogenase
AKR1C4

Sterol 27-hydroxylase
CYP27A1

Bile acid CoA synthetase (BACS)
or very long chain acyl CoA
synthetase (VLCS)

Side-chain modification by
4 peroxisomal enzymes
(AMACR, BCOX, BDP, SCPx)

Amino acid N-acyltransferase
(BAAT)

Amino acid N-acyltransferase
(BAAT)

7α-hydroxycholesterol

7α-hydroxy
4 cholesten-3-one

7α-12α-dihydroxy
-4 cholesten-3-one

7α-dihydroxy-5β-
cholestan-3-one

5β-cholestan-
3α,7α -diol

3α,7α-dihydroxy-5β-
cholestanoic acid (DHCA)

DHCA-CoA

Chenodeoxycholic
acid

Glyco or tauro-
chenodeoxycholic acid

Glyco or tauro-
cholic acid

Cholic acid

3α,7α,12α-trihydroxy-5β-
cholestanoic acid (THCA)

5β-cholestan-
3α,7α,12α-triol

7α-12α-dihydroxy-
5β-cholestan-3-one

THCA-CoA

Microsomes

Cytosol

Mitochondria

peroxisomes

hepatocyte

Endoplasmic
reticulum

Sterol 12α-hydroxylase
CYP8B1

AMARC: alpha methylacyl-CoA racemase

BCOX: Branched-chain acyl CoA oxydase

BDP: D-bifunctional protein hydratase

SCPx: Sterol carrier protein

Alternative pathway

Cholesterol

Oxysterol 7α-hydroxylase
CYP7B1

3β-hydroxy-Δ5-C27-steroid dehydrogenase
HSD3B7

Side-chain modifications

Sterol 27-hydroxylase
CYP27A1

Amino acid N-acyltransferase
(BAAT)

3β-hydroxy-5-cholestanoic acid

3-oxo-7α-hydroxy-4-cholestanoic acid

3β,7α-dihydroxy-5-cholestanoic acid

Chenodeoxycholic acid

Glyco or tauro-
chenodeoxycholic acid

adapted from Sundaram 20081

1. Sundaram SS, Bove KE, Lovell MA, Sokol RJ. Mechanisms of disease: Inborn errors of bile acid synthesis. Nat Clin Pract Gastroenterol Hepatol 2008;5:456-68.

2. Monte MJ, Marin JJG, Antelo A, Vazquez-Tato J. Bile acids: chemistry, physiology, and pathophysiology. World J Gastroenterol 2009;15:804-16

​TH-BAS10EN/01/02/2024



REMINDER ABOUT BILE ACIDS

The bile acid family is a group of acid steroids synthesised from cholesterol in the liver. Although their best-known role is to aid with the emulsion, digestion and absorption of fats and liposoluble vitamins, other important physiological roles have been identified.1

On secretion of bile acids into bile canaliculi, osmotic pressure is created that accounts for the bile-acid-dependent fraction of bile flow. Bile acids stimulate biliary lipid secretion and form mixed micelles with biliary phospholipids, allowing the solubilisation of cholesterol and other lipophilic compounds in the bile. The mixed micelles also emulsify dietary fats in the intestines, facilitating their absorption.1

Bile acid synthesis

The primary bile acids, cholic acid and chenodeoxycholic acid are synthesised from cholesterol by an enzymatic cascade involving nearly 20 enzymes and two complementary chemical pathways, the classic “neutral” pathway and the alternative “acidic” pathway.2,3 Although the neutral pathway is believed to be the major pathway for bile acid synthesis in adults, in the first months of life the acidic pathway is thought to be more important.2,5 In humans and under normal conditions, the acidic pathway contributes little (approximately 10%) to the restitution of daily loss of bile acid.1 It may become the major bile acid biosynthetic pathway in patients with liver diseases.1

The primary bile acids produced include cholic acid (CA), which accounts for approximately 70% of the circulating pool of bile acids, and chenodeoxycholic acid (CDCA), which accounts for approximately 30% of the pool.4

Enzymatic pathways of bile acid synthesis

classic pathway

adapted from Sundaram 20083 and Monte 20091

Cholesterol

Cholesterol 7α-hydroxylase
CYP7A1

3β-hydroxy-Δ5 -C27-steroid dehydrogenase
HSD3B7

Δ4-3-oxosteroid-5β-reductase
AKR1D1

Δ4-3-oxosteroid-5β-reductase
AKR1D1

3α-hydroxysteroid dehydrogenase
AKR1C4

Sterol 27-hydroxylase
CYP27A1

Bile acid CoA synthetase (BACS)
or very long chain acyl CoA
synthetase (VLCS)

Side-chain modification by
4 peroxisomal enzymes
(AMACR, BCOX, BDP, SCPx)

3α-hydroxysteroid dehydrogenase
AKR1C4

Sterol 27-hydroxylase
CYP27A1

Bile acid CoA synthetase (BACS)
or very long chain acyl CoA
synthetase (VLCS)

Side-chain modification by
4 peroxisomal enzymes
(AMACR, BCOX, BDP, SCPx)

Amino acid N-acyltransferase
(BAAT)

Amino acid N-acyltransferase
(BAAT)

7α-hydroxycholesterol

7α-hydroxy
4 cholesten-3-one

7α-12α-dihydroxy
-4 cholesten-3-one

7α-dihydroxy-5β-
cholestan-3-one

5β-cholestan-
3α,7α -diol

3α,7α-dihydroxy-5β-
cholestanoic acid (DHCA)

DHCA-CoA

Chenodeoxycholic
acid

Glyco or tauro-
chenodeoxycholic acid

Glyco or tauro-
cholic acid

Cholic acid

3α,7α,12α-trihydroxy-5β-
cholestanoic acid (THCA)

5β-cholestan-
3α,7α,12α-triol

7α-12α-dihydroxy-
5β-cholestan-3-one

THCA-CoA

Microsomes

Cytosol

Mitochondria

peroxisomes

hepatocyte

Endoplasmic
reticulum

Sterol 12α-hydroxylase
CYP8B1

AMACR: alpha methylacyl-CoA racemase

BCOX: Branched-chain acyl CoA oxydase

BDP: D-bifunctional protein hydratase

SCPx: Sterol carrier protein

The classic pathway, also known as the “neutral” pathway because its intermediate metabolites are neutral sterols, is the main pathway for bile acid synthesis.1-3 It is present only in the liver and synthesises cholic acid and chenodeoxycholic acid.1 This pathway consists of a cascade of reactions catalysed by enzymes located in microsomes, the cytosol, mitochondria and peroxisomes.1 The final step in the synthesis of bile acid is the conjugation of cholic acid and chenodeoxycholic acid to taurine or glycine.3

Alternative pathway

Cholesterol

Oxysterol 7α-hydroxylase
CYP7B1

3β-hydroxy-Δ5-C27-steroid dehydrogenase
HSD3B7

Side-chain modifications

Sterol 27-hydroxylase
CYP27A1

Amino acid N-acyltransferase
(BAAT)

3β-hydroxy-5-cholestanoic acid

3-oxo-7α-hydroxy-4-cholestanoic acid

3β,7α-dihydroxy-5-cholestanoic acid

Chenodeoxycholic acid

Glyco or tauro-
chenodeoxycholic acid

adapted from Sundaram 2008 and Monte 20091

The alternative pathway involves C27-hydroxylation of cholesterol by sterol 27-hydroxylase as the initial step: side-chain oxidation of cholesterol precedes steroid ring modification.1,3 Thus, acidic intermediate metabolites are formed: this is why this pathway is also known as the “acidic” pathway.1 It primarily produces chenodeoxycholic acid.3

Regulation of bile acid synthesis

Bile acid synthesis is tightly regulated to ensure homeostatic levels of cholesterol are produced and to provide adequate emulsification in the intestine. An excess of bile acids has a negative feedback effect, repressing further synthesis; conversely, when bile acids levels are low, synthesis is increased.2,6

In the ‘neutral’ pathway, the rate-limiting step is the modification of the steroid nucleus, which takes place in hepatic microsomes and is catalysed by cholesterol 7α-hydroxylase (CYP7A1). The neutral pathway facilitates the transformation of cholesterol to cholic acid and chenodeoxycholic acid, which are further conjugated to glycine or taurine and used as substrates for the bile acid transport pump. The canalicular transport of bile acid is the rate-limiting step of bile secretion. Bile acids are recovered from the intestines by the apical sodium-dependent bile acid transporter and return to the liver via the portal blood. The gene encoding CYP7A1 is highly regulated by negative feedback involving farnesoid X receptor (FXR)-dependent induction of fibroblast growth factor 15/19 (FGF15/19) expression by bile acids in the enterocytes. FGF15/19 binds to the fibroblast growth factor receptor 4-β-klotho complex in hepatocytes, activating signalling pathways that transcriptionally repress CYP7A1 expression.2

Enterohepatic circulation of bile acids

Bile acids are mostly restricted to enterohepatic circulation, circulating between the liver, the biliary tree, the intestine, and the portal blood which returns them to the liver. Almost all (95%) the bile acids are recovered from the intestine, mostly in the ileum.1 The liver converts around 500 mg of cholesterol into bile acids per day. This accounts for 90% of the cholesterol that is actively metabolized by the body. The remaining 10% of cholesterol that is synthesised is biosynthesised from steroid hormones.6

Newly synthesised bile acids are secreted into the bile where they are transported to the lumen of the small intestine, where they act as lipid emulsifiers, solubilising nutrients. These nutrients are incorporated into lipoproteins, and are delivered via the portal vein to the liver and metabolised. About 95% of the bile acids are recycled and secreted back into the bile. The remaining 5% are excreted into the faeces.6-7

Enterohepatic circulation of bile acids

adapted from van Mil 20057

ENTEROHEPATIC CYCLE

1. Monte MJ, Marin JJG, Antelo A, Vazquez-Tato J. Bile acids: chemistry, physiology, and pathophysiology. World J Gastroenterol 2009;15:804-16.

2. Jahnel J, Zöhrer E, Fischler B, et al. Attempt to determine the prevalence of two inborn errors of primary bile acid synthesis: results of a European survey. J Pediatr Gastroenterol Nutr 2017;64:864-8.

3. Sundaram SS, Bove KE, Lovell MA, Sokol RJ. Mechanisms of disease: Inborn errors of bile acid synthesis. Nat Clin Pract Gastroenterol Hepatol 2008;5:456-68.

4. Ashby K, Navarro Almario EE, Tong W, Borlak J, Mehta R, Chen M. Review article: therapeutic bile acids and the risks for hepatotoxicity. Aliment Pharmacol Ther 2018;47:1623-38.

5. Clayton PT. Disorders of bile acid synthesis. J Inherit Metab Dis 2011;34:593-604.

6. Russell DW. The enzymes, regulation, and genetics of bile acid synthesis. Annu Rev Biochem 2003;72:137-74.

7. van Mil SW, Houwen RH, Klomp LW. Genetics of familial intrahepatic cholestasis syndromes. J Med Genet 2005;42:449-63.

​TH-BAS10EN/01/02/2024

Normal values:

Vitamin A: 1,09-3,07 μmol/L

Vitamin E: 25-42 μmol/L

AST: <39 U/L

ALT: <34 U/L

GGT: <38 U/L

Total bilirubin: <17 μmol/L

Conjugated bilirubin level: <5 μmol/L

Normal values:

AST: < 45 mU/mL

International normalized ratio: < 1.2

Prothrombin ratio: 70-120 %

Factor VII: 70-120 %

Factor X: 70-120 %

Vitamin E: 300-1200 μg/dL

If you click on “access to the link”, you will move on to another website in a new tab

CTRS is not responsible for the content on this website

Bilirubin metabolism5-7

Important things to check: the degree and duration of stool discolouration. The colour of the stool should ideally be recorded after elimination of any component likely to change the colour and with the help of a colour chart:2, 14

This chart is used with the kind permission of the AMFE, Association Maladies Foie Enfants, a French association dedicated to liver diseases in children.3

You can also refer to the stool chart provided by the Children’s Liver Disease Foundation (CLDF), a UK charity committed to fighting all childhood liver diseases :

CLDF-Yellow-Alert-Stool-Chart

Persistently pale coloured stools may indicated liver disease.14  Complete and prolonged discolouration of stools for 7 days is suggestive of biliary atresia until proven otherwise. However, the sign is not specific to biliary atresia and can also occur, among others, in conditions such as cystic fibrosis, Alagille syndrome, alpha-1 antitrypsin deficiency and neonatal sclerosing cholangitis.2

​TH-BAS08EN/01/02/2024

What causes (rare) cholestasis
in paediatric patients

?

Menu

To access the platform and the
diagnostic algorithms,
please confirm:

If you are not a healthcare professional, please do not access the website as the content is not suitable. We invite you to continue your research through another website

Created by

Created by

Content reviewed by experts in paediatric gastroenterology and hepatology.

This website was created by Theravia. Theravia is a leading international pharmaceutical laboratory specializing in rare or neglected diseases. Formed through the merger of Addmedica and CTRS, we are dedicated to address the unmet medical needs of patients with these challenging conditions

03/2024

What causes (rare) cholestasis
in paediatric patients ?

Menu

To access the platform and the
diagnostic algorithms,
please confirm:

If you are not a healthcare professional, please do not access the website as the content is not suitable.
We invite you to continue your research through another website

This website was created by Theravia. Theravia is a leading international pharmaceutical laboratory specializing in rare or neglected diseases. Formed through the merger of Addmedica and CTRS, we are dedicated to address the unmet medical needs of patients with these challenging conditions

Created by

Content reviewed by experts in paediatric gastroenterology and hepatology.
